Teknik özellikler
- Product specifications
-
Product specifications Model Number - 861304
Waveform - Truncated Exponential Biphasic. Waveform parameters adjusted as a function of each patient’s impedance.
Battery - Typically 4 years when stored and maintained according to directions provided in Owner’s Manual. Standby life (after insertion):
Therapy - Adult defibrillation peak current: 32A (150J nominal) into a 50 ohm load. Pediatric defibrillation (with optional Infant/Child Key installed): 19A (50J nominal) into a 50 ohm load.
Protocol - Protocol Device follows preconfigured settings. Defibrillation and CPR protocol can be customized using HeartStart Event Review or HeartStart Configure software.
Quick Shock - Able to deliver a shock after the end of a CPR interval, typically in eight seconds.
-
- Physical requirements
-
Physical requirements Size - 2.4 x 7.1 x 8.9 inches (6 x 18 x 22 cm) H x D x W
Weight - With battery and pads case: 3.5 lbs (1.5 kg) Without battery or pads case: 2.6 lbs (1.2 kg)
-
- Environmental
-
Environmental Temperature - Operating/Standby:32° - 122° F (0° - 50° C)
EMI (Radiated/Immunity) - CISPR II Group I Class B, IEC 61000-4-3, and IEC 61000-4-8
Sealing - Waterjet proof IPX5 per IEC60529 Dust protected IPX5 per IEC60529
Altitude - 0 to 15,000 feet
Aircraft - Device: RTCA/DO-160D;1997
Crush - 500 pounds
Vibration - Operating: meets MILSTD 810F Fig.514.5C-17, random Standby: meets MILSTD 810F Fig.514.5C-18,swept sine.
-
- Product specifications
-
Product specifications Model Number - 861304
Waveform - Truncated Exponential Biphasic. Waveform parameters adjusted as a function of each patient’s impedance.
-
- Physical requirements
-
Physical requirements Size - 2.4 x 7.1 x 8.9 inches (6 x 18 x 22 cm) H x D x W
Weight - With battery and pads case: 3.5 lbs (1.5 kg) Without battery or pads case: 2.6 lbs (1.2 kg)
-
- Product specifications
-
Product specifications Model Number - 861304
Waveform - Truncated Exponential Biphasic. Waveform parameters adjusted as a function of each patient’s impedance.
Battery - Typically 4 years when stored and maintained according to directions provided in Owner’s Manual. Standby life (after insertion):
Therapy - Adult defibrillation peak current: 32A (150J nominal) into a 50 ohm load. Pediatric defibrillation (with optional Infant/Child Key installed): 19A (50J nominal) into a 50 ohm load.
Protocol - Protocol Device follows preconfigured settings. Defibrillation and CPR protocol can be customized using HeartStart Event Review or HeartStart Configure software.
Quick Shock - Able to deliver a shock after the end of a CPR interval, typically in eight seconds.
-
- Physical requirements
-
Physical requirements Size - 2.4 x 7.1 x 8.9 inches (6 x 18 x 22 cm) H x D x W
Weight - With battery and pads case: 3.5 lbs (1.5 kg) Without battery or pads case: 2.6 lbs (1.2 kg)
-
- Environmental
-
Environmental Temperature - Operating/Standby:32° - 122° F (0° - 50° C)
EMI (Radiated/Immunity) - CISPR II Group I Class B, IEC 61000-4-3, and IEC 61000-4-8
Sealing - Waterjet proof IPX5 per IEC60529 Dust protected IPX5 per IEC60529
Altitude - 0 to 15,000 feet
Aircraft - Device: RTCA/DO-160D;1997
Crush - 500 pounds
Vibration - Operating: meets MILSTD 810F Fig.514.5C-17, random Standby: meets MILSTD 810F Fig.514.5C-18,swept sine.
-
